Reliance Water Columns & Water Gage Valves (Clark-Reliance) support boiler water level indication, alarm, and control applications across a wide range of operating pressures. These boiler trim products help operators monitor water level, protect equipment, and support safe boiler operation.
Reliance water columns are available in cast iron, steel, and standpipe configurations. Depending on the application, they can support direct-reading water gages, float alarms, probe-type alarm systems, low water cut-out functions, and pump control. In addition, Reliance water gage valves are available in bronze and forged steel models for low, medium, and high-pressure steam service.
All Reliance water columns and components follow ASME Boiler Code requirements. Steel water columns use qualified welding procedures, while columns and components undergo hydrostatic testing to 150% of design pressure. As a result, these products suit demanding boiler applications where dependable level indication matters.
Westech Industrial supplies Reliance water columns, standpipes, and water gage valves for boiler applications across Canada. Our team can also support boiler trim selection, service requirements, custom fabrication, and integrated solutions for new installations or retrofit projects.
Quantity
PRODUCT FEATURES
REQUEST FOR INFORMATION
Description
ASME Code-Focused Boiler Trim
Reliance water columns help operators monitor boiler water level with dependable boiler trim components. Clark-Reliance manufactures these columns, standpipes, and valves for ASME Boiler Code applications. Therefore, they suit plants that need reliable water level indication and clear configuration options.
Reliance also hydrostatically tests water columns and related components to 150% of their design pressure. This testing supports confidence in demanding steam service. In addition, steel water columns use qualified welding procedures that meet ASME requirements.
Cast Iron and Steel Water Column Options
Reliance water columns include cast iron and steel options for different boiler requirements. The W0250 cast iron water column comes in float type and probe type configurations. The float type supports low and high alarm functions. Meanwhile, the probe type can support alarms, low water cut-out, high water cut-out, and pump control functions.
Steel water columns offer more flexibility for higher pressure applications. They allow project teams to specify connection arrangement, boiler design pressure, alarm type, steam and water centers, connection sizes, normal water level location, alarm spacing, and gage visibility range.
Standpipes for Compact Gage Support
SP Series standpipes provide a compact option when probe alarms are not required. They support gage glasses and help reduce field welding. As a result, contractors can simplify connection layout and improve installation planning.
Reliance builds standpipes from heavy wall ASME-SA106 Grade B carbon steel pipe. A wide variety of connections can also support different boiler trim specifications.
Bronze and Steel Water Gage Valve Choices
Reliance water gage valves include bronze and steel models. Bronze valves come in 12 models for pressures up to 450 PSI (30 Bar). Steel valves come in 16 models for pressures up to 3000 PSI (200 Bar).
Bronze BG Series valves include compliant bronze bodies, integral seats, an 18-position gage lever, and screwed or flanged connections. Their quadruple stem threads allow full open or closed operation with one-quarter turn.
For higher pressure service, SG800 forged steel lever-operated valves support steam service up to 1500 PSI (100 Bar). SG600 and SG700 forged steel chain wheel valves support service up to 3000 PSI (200 Bar). These steel valve options include forged steel bodies, stainless steel stems, Grafoil packing cartridges, and blowdown connections.
Alarm, Cut-Out, and Control Options
Probe type Reliance water columns can support multiple boiler control functions. Depending on the model, they can provide high and low water alarms, low water cut-out, high water cut-out, and pump control.
Relay controls support probe safety systems for applications up to 3000 PSI. They provide low voltage power to probes, include LED status indication, and support common plant alarm or control requirements.
Applications
Reliance water columns and water gage valves support boiler level indication, alarm, and control applications. They are commonly used where operators need dependable local level visibility and code-compliant boiler trim.
- Boiler water level indication
- Steam drum level monitoring
- Low and high water alarm applications
- Low water cut-out applications
- High water cut-out applications
- Pump control applications
- Water gage glass support
- Boiler retrofit projects
- Power and utility boiler systems
- Industrial steam boiler systems
- Direct-to-drum level gage assemblies
- Standpipe-supported gage glass installations
Documents
Manufacturer Info
Clark-Reliance® Corporation is a global leader in the level indication and control, sightflow indication, filtration and separation industries. The company’s well-known brands constitute the broadest line of level instrumentation for boilers and other equipment found in utilities, refineries, chemical processing and other industries.
