Reliance Prismatic Water Gages, Flat Glass Water Gages & DuraStar® Illumination (clark-reliance)

Westech Industrial supplies the full range of Clark‑Reliance boiler water‑level gages, combining prismatic (reflex) water gages, flat‑glass water gages and the DuraStar® LED illuminator. These products offer high contrast visibility, proven reliability and flexible configuration to suit everything from low‑pressure heating boilers to high‑pressure industrial steam drums. Below you’ll find a summary of the key features and benefits.

• Prismatic (Reflex) Water Gage Glasses
  Reliance prismatic, or reflex, water gages use a series of precision‑cut prisms on the inside surface of the glass. Light passing through these prisms is either totally reflected in the steam space or transmitted through the liquid, creating a sharp black‑and‑white image of the water level
  This prismatic principle makes the water line easy to distinguish without the need for external lighting.Key features of the prismatic gage line include:

• • Distinct, easy‑to‑read display – reflex prisms provide a clear, unambiguous image of the water level, reducing reading errors
  • Versatile installation – gages can be mounted vertically or on Tiltview™ assemblies and are available in multiple sections to extend the viewing area
  • Two pressure ratings – “C” types are rated for boilers up to 250 psi and “S” types up to 350 psi Typical applications include boiler drums, feedwater heaters, deaerators and storage tanks.
  • Quality materials and clamping design – each reflex gage uses high‑quality borosilicate glass tempered for toughness. Reliance’s unique clamping design applies a uniform compressive load across the glass for better seal integrity and longer service life.
  • Multi‑section assemblies – double, triple and quadruple sections are available for tall vessels. Reinforcing bars on three or more sections keep all gage bodies properly aligned.
• Flat Glass Water Gages (FG Series)
  Where operators prefer a traditional transparent sight glass, the Reliance FG Series flat‑glass gages provide proven strength and visibility. Precision manufacturing and a wide‑body construction assure outstanding performance and long service life.Key attributes of the FG Series include:
  • Wide‑body construction for added strength and rigidity
  • Premium tempered glass that resists thermal shock; every glass pane is tested for surface trueness and protected by a high‑quality mica shield
  • Uniform finger‑clamp design to ensure gasket tightness and simplify maintenance
  • High‑visibility window slot – the 5/8 inch (15.9 mm) wide slot makes it easy to read the water level, and gages are available with single, double or triple windows for extended viewing
• DuraStar Illumination
  For applications where lighting is poor or where a clear level indication is critical, Reliance’s DuraStar LED illuminator is the ideal accessory. The illuminator attaches directly to any FG Series gage without tools and uses three columns of directed amber LEDs to create a bright, star‑like image of the water line.Benefits of DuraStar illumination include:
  • High contrast day or night – amber LEDs highlight the meniscus for superior visibility
  • Long life and low maintenance – the LEDs are rated for around 100 000 hours of service and generate virtually no heat
  • Versatile operation – the illuminator can run continuously or be switched on only when needed
  • Suitable for hazardous or ordinary locations – DuraStar models are available for ordinary, Class 1 Division 1 and ATEX environments
